恒温晶振 (OCXO) 温补晶振 (TCXO) 压控晶振 (VCXO) 晶体振荡器 (XO) 晶体谐振器(Crystal) 晶体滤波器(Crystal Filters) LC滤波器模块(LC Filter) 放大器(Amplifier) 压控振荡器(VCO) 滤波器组模块(Filter Bank) 时钟模块 (Timing Module) 带阻滤波器(Bandstop Filter) 声表面波滤波器（SAW Filter） 锁相介质振荡器(PLDRO) 锁相环(PLL)
| 产品型号 | 规格书 | 产品图片 | 供电电压 (V) |
频率 (MHz) |
输出类型 | 频率稳定度 (ppm) |
工作温度范围 (°C) |
封装尺寸 长 x 宽 x 高 (mm) |
| VCXO5300S-CMOS |
|
|
3.3 | 1.5 to 170 | CMOS |
25, 50 APR > 50 |
-20 to +70 -40 to +85 |
5.0 x 3.2 x 1.3 6-pad |
| VCXO5300S-LPLV |
|
|
3.3 | 20.0 to 200 | LVDS, LVPECL |
25, 50 APR > 50 |
-20 to +70 -40 to +85 |
5.0 x 3.2 x 1.3 6-pad |
| VCXO2520BM-LJ_LVPECL |
|
|
2.5, 3.3 | 15-2100 | LVPECL | ±20 | -40 to +85 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVDS |
|
|
1.8, 2.5, 3.3 | 15-2100 | LVDS | ±20 | -40 to +85 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-122.88MHz-132 |
|
|
3.3 | 122.88 | LVPECL | ±50 | -10 to +60 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-122.88MHz-142 |
|
|
3.3 | 122.88 | LVPECL | ±100 | -10 to +60 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-122.88MHz-332 |
|
|
3.3 | 122.88 | LVPECL | ±50 | -40 to +85 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-122.88MHz-342 |
|
|
3.3 | 122.88 | LVPECL | ±100 | -40 to +85 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVDS-122.88MHz-142 |
|
|
3.3 | 122.88 | LVDS | ±100 | -10 to +60 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVDS-122.88MHz-222 |
|
|
3.3 | 122.88 | LVDS | ±25 | -20 to +70 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-121 |
|
|
2.5 | 15-2100 | LVPECL | ±25 | -10 to +60 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-111 |
|
|
2.5 | 15-2100 | LVPECL | ±20 | -10 to +60 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-131 |
|
|
2.5 | 15-2100 | LVPECL | ±50 | -10 to +60 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-141 |
|
|
2.5 | 15-2100 | LVPECL | ±100 | -10 to +60 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-221 |
|
|
2.5 | 15-2100 | LVPECL | ±25 | -20 to +70 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-231 |
|
|
2.5 | 15-2100 | LVPECL | ±50 | -20 to +70 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-241 |
|
|
2.5 | 15-2100 | LVPECL | ±100 | -20 to +70 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-331 |
|
|
2.5 | 15-2100 | LVPECL | ±50 | -40 to +85 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-341 |
|
|
2.5 | 15-2100 | LVPECL | ±100 | -40 to +85 | 2.5 x 2 x 1 |
| VCXO2520BM-LJ_LVPECL-112 |
|
|
3.3 | 15-2100 | LVPECL | ±20 | -10 to +60 | 2.5 x 2 x 1 |
