| 产品型号 | 规格书 | 产品图片 | 供电电压 (V) |
频率 (MHz) |
输出类型 | 频率稳定度 (ppm) |
工作温度范围 (°C) |
封装尺寸 长 x 宽 x 高 (mm) |
| VCXO5300R-LVDS |
|
|
3.3 | 10 to 1450 | LVDS | 50, 100 |
-10 to +70 -40 to +85 |
5.0 x 3.2 x 1.2 |
| VCXO7500R-LVDS |
|
|
3.3 | 10 to 1450 | LVDS | 50, 100 |
-10 to +70 -40 to +85 |
7.0 x 5.0 x 1.8 |
| VCXO7500S-LVPECL |
|
|
3.3 | 100 to 800 | LVPECL | 25, 50 |
-10 to +70 -40 to +85 |
7.0 x 5.0 x 1.8 |
| VCXO3225AL-CMOS |
|
|
2.5, 3.3 | 10 to 250 | CMOS | 25, 50 |
-20 to +70 -40 to +85 |
3.2 x 2.5 x 0.95 |
| VCXO5032AL-CMOS |
|
|
2.5, 3.3 | 10 to 250 | CMOS | 25, 50 |
-20 to +70 -40 to +85 |
5.0 x 3.2 x 1.25 |
| VCXO7500AL-CMOS |
|
|
2.5, 3.3 | 10 to 250 | CMOS | 25, 50 |
-20 to +70 -40 to +85 |
7.0 x 5.0 x 1.45 |
| VCXO3225AL-LVPECL |
|
|
2.5, 3.3 | 10 to 1500 | LVPECL | 25, 50 |
-20 to +70 -40 to +85 |
3.2 x 2.5 x 0.9 |
| VCXO5032AL-LVPECL |
|
|
2.5, 3.3 | 10 to 1500 | LVPECL | 25, 50 |
-20 to +70 -40 to +85 |
5.0 x 3.2 x 1.25 |
| VCXO7500AL-LVPECL |
|
|
2.5, 3.3 | 10 to 1500 | LVPECL | 25, 50 |
-20 to +70 -40 to +85 |
7.0 x 5.0 x 1.45 |
| VCXO3225AL-CMOS-10MHz-111 |
|
|
3.3 | 10 | CMOS | ±25 | -20 to +70 | 3.2 x 2.5 x 0.95 |
| VCXO3225AL-CMOS-10MHz-121 |
|
|
3.3 | 10 | CMOS | ±50 | -20 to +70 | 3.2 x 2.5 x 0.95 |
| VCXO3225AL-CMOS-10MHz-211 |
|
|
3.3 | 10 | CMOS | ±25 | -40 to +85 | 3.2 x 2.5 x 0.95 |
| VCXO3225AL-CMOS-10MHz-221 |
|
|
3.3 | 10 | CMOS | ±50 | -40 to +85 | 3.2 x 2.5 x 0.95 |
| VCXO3225AL-LVPECL-10MHz-111 |
|
|
3.3 | 10 | LVPECL | ±25 | -20 to +70 | 3.2 x 2.5 x 0.9 |
| VCXO3225AL-LVPECL-10MHz-121 |
|
|
3.3 | 10 | LVPECL | ±50 | -20 to +70 | 3.2 x 2.5 x 0.9 |
| VCXO3225AL-LVPECL-10MHz-211 |
|
|
3.3 | 10 | LVPECL | ±25 | -40 to +85 | 3.2 x 2.5 x 0.9 |
| VCXO3225AL-LVPECL-10MHz-221 |
|
|
3.3 | 10 | LVPECL | ±50 | -40 to +85 | 3.2 x 2.5 x 0.9 |
| VCXO5032AL-CMOS-10MHz-111 |
|
|
3.3 | 10 | CMOS | ±25 | -20 to +70 | 5.0 x 3.2 x 1.25 |
| VCXO5032AL-CMOS-10MHz-121 |
|
|
3.3 | 10 | CMOS | ±50 | -20 to +70 | 5.0 x 3.2 x 1.25 |
| VCXO5032AL-CMOS-10MHz-211 |
|
|
3.3 | 10 | CMOS | ±25 | -40 to +85 | 5.0 x 3.2 x 1.25 |
| VCXO1490BE-4P_Sine-100MHz-5311 |
|
|
3.3 | 100 | Sinewave | ±20 | -40 to +85 | 14.4 x 9.3 x 2.7 |
| VCXO1490BM-LN2-100MHz-A-V |
|
|
3.3 | 100 | CMOS | ±25 | -40 to +85 | 13.9 x 9.1 x 3.6 |
