恒温晶振 (OCXO) 温补晶振 (TCXO) 压控晶振 (VCXO) 晶体振荡器 (XO) 晶体谐振器(Crystal) 晶体滤波器(Crystal Filters) LC滤波器模块(LC Filter) 带阻滤波器(Bandstop Filter) 声表面波滤波器（SAW Filter） 腔体滤波器(Cavity Filter) 放大器(Amplifier) 滤波器组模块(Filter Bank) 压控振荡器(VCO) 时钟模块 (Timing Module) 锁相介质振荡器(PLDRO) 锁相环(PLL)
| 产品型号 | 规格书 | 产品图片 | 供电电压 (V) |
频率 (MHz) |
日老化率 (ppb/day) |
频率稳定度 (ppb) |
工作温度范围 (°C) |
封装尺寸 长 x 宽 x 高 (mm) |
| OCXO3306C |
|
|
3.3, 5 | 8 to 120 | 0.1 | 50 | -30 to +70 | 21.51 x 15.1 x 8.0 |
| OCXO3312C |
|
|
3.3, 5 | 8 to 150 | 0.5 | 5 | -40 to +85 | 15.9 x 15.1 x 8.8 DIP |
| OCXO3313C |
|
|
3.3, 5 | 8 to 150 | 0.5 | 5 | -40 to +85 | 15.9 x 15.1 x 8.8 SMD |
| OCXO3307C |
|
|
3.3, 5 | 8 to 150 | 0.2 | 3 | -40 to +85 | 21.51 x 15.1 x 8.8 DIP |
| OCXO3308C |
|
|
3.3, 5 | 8 to 150 | 0.2 | 3 | -40 to +85 | 21.51 x 15.1 x 8.8 SMD |
| OCXO3311C |
|
|
3.3, 5 | 8 to 100 | 0.5 | 50 | -30 to +70 | 15.9 x 15.1 x 10.0 |
| OCXO3315C |
|
|
3.3, 5 | 8 to 100 | 0.5 | 5 | -55 to +85 | 21.85 x 15.1 x 10.0 |
| OCXO3316C |
|
|
3.3, 5 | 30 to 300 | 1 | 5 | -55 to +85 | 21.85 x 15.1 x 10.0 |
| OCXO3309-40MHz-A-V |
|
|
5 | 40 | ±1.5 | ±50 | -40 to +85 | 16 x 15.3 x 9.5 |
| OCXO2020CV-LP |
|
|
3.3, 5 | 8 to 150 | ±0.03 | ±0.5 | -40 to +85 | 20.2 x 20.2 x 12.6 |
| OCXO9700BM-30.72MHz-B |
|
|
3.3 | 30.72 | ±5 | ±20 | -40 to +85 | 9.7 x 7.5 x 4.1 |
| OCXO2114BM-LP-16.384MHz-A-V |
|
|
3.3 | 16.384 | ±0.2 | ±10 | -40 to +85 | 20.5 x 15.25 x 10.5 |
| OCXO2114BM-LP-10MHz-A-V |
|
|
3.3 | 10 | ±0.3 | ±10 | -40 to +85 | 20.5 x 15.25 x 10.5 |
